Chamberlain Elite SL3000UL User Manual

2323
ENTRAPMENT PROTECTION DEVICES
Contact Sensors (Edge Sensor)
NOTE: When touched, these electrically activated edge sensors immediately signal the gate operator to stop and reverse. Property
owners are obligated to test edges monthly. See Accessories.
Connect all edge sensors
to the sensor connection.
Close
Sensor
on Wall
Open
Sensor
on Wall
Close Sensor on Gate
Open Sensor
on Wall
Open Sensor on Gate
Gate in Open Position
Gate in Open Position
Parallel
Connection
To prevent SERIOUS INJURY or DEATH from a moving gate:
• Locate entrapment protection devices to protect in BOTH the open and close gate cycles.
• Locate entrapment protection devices to protect between moving gate and RIGID objects, such as posts or walls.
WARNING
WARNING
CAUTION
ENGLISH
SPANISH
ADVERTENCIA
ADVERTENCIA
PRECAUCI” N
ADVERTENCIA
WARNING
