2525
CENTER SAFETY EXIT
CENTER SAFETY EXIT
FIRE
DEPT.
STRIKE
OPEN
RADIO
RECEIVER
TIMER
SYSTEM ON
EXIT
LOOP
ALARM
SENSOR
REVERSE
SENSOR
OPEN
STOP CLOSE
SAFETY
LOOP
CENTER
LOOP
GATE
LOCKED
60
POWER
OVERLOAD
OFF
W4
OPEN LEFT
DC-BACKUP
ALARM SENSOR
OPEN RIGHT
3
SENSORS
RESET
MOTOR
COMMAND
PROCESSED
ON
G B
MS LINK
A
QCC
A B
OPEN STOP CLOSE MAGLOCK ALARM
ARMED
M/S LINK
N.O.
N.O.
N.O.
N.O.
N.C.
N.C.
N.C.
Ground
Ground
Comm
Comm
Ground
Ground
B A
W4
W4
G
OMNI OPTION BOARD CONNECTIONS
Purchased separately from Chamberlain Elite. See Accessories.
NOTE: Cut jumper W4 wire ONLY when installing a
3 button station, stop button, or QCC.
Stop
Button
Dry Contact
3 Button
Station
Dry Contact
Second
Operator
Proximity
Switch
12Vdc House Alarm
Maglock
Solenoid Lock
Relay Contact Rating
0.5 Amp - 125Vac
1 Amp - 24Vdc
NOTE: Refer to the Omni
Option Board manual for
more specific information.
Quick Close Circuit
Allows the gate’s close
cycle to close quicker than
the OmniControl™ timer will
allow. Refer to the QCC
manual for more specific
information.
See Accessories.
To Next Page
