SET GATE OPENING DIRECTION
Push and hold lock plate to release limit nuts.
Open to the LEFT Open to the RIGHT
Roll limit nuts to adjust the open and close limit switches.
Each notch on limit nut
is an estimated one inch
of gate travel.
To reduce the risk of SERIOUS INJURY or DEATH:
Disconnect electric power BEFORE performing ANY
adjustments.
WARNING
WARNING
CAUTION
ENGLISH
SPANISH
ADVERTENCIA
ADVERTENCIA
PRECAUCIÓN
ADVERTENCIA
WARNING
LIMIT SWITCH ADJUSTMENTS
