4.2.11.3.1 Receiver NMEA output
When set receiver COM2 to output NMEA, it is necessary to use COM2 NMEA cable
(PN: 4103020118).
Please go to Receiver NMEA Output, then it is able to select header is GP or GN
format which depends on the terminal devices decoding method, and 7 different
NMEA message types including GGA, VTG, GSA, GST, GSV, ZDA and RMC with 5s to
10hz outputting frequency, then users can configure the baud rate from 9600 to
115200, finally it is necessary to enable the message status what configured. On the
terminal side, it will decode the NMEA messages and get the correction information
to display.
4.2.11.3.2 Tablet NMEA output
When set tablet to output NMEA, it is necessary to use adapter NMEA cable(PN:
4103020151).
Please go to Tablet NMEA Output, then it is able to find header is GP or GN, and 7
different NMEA message types including GGA, VTG, GSA, GST, GSV, ZDA and RMC
