Chenbro RM23808 User Manual

RM238 Series
Product Overview│ 8
1. Product Overview
RM238 series offers a variety of system options to meet the various configuration requirements of high-density/high-performance
computing environments. This 2U chassis supports both 2.5” and 3.5” storage form factors with different drive bay configurations.
This chapter provides a high-level overview of the system features and available options. More details for each major sub-systme,
feature, or option are provided in the following chapters.
Table 1 Chenbro RM23808/12/24 specifications
Feature
Description
MB Form Factor
 SSI EEB (12” x 13”)
Dimension
(D x W x H)
 658.6 x 438.0 x 87.0 (mm)
25.93” x 17.24” x 3.43”
Drive Bay
 RM23808: 8 x 3.5” Hot-swap, 2 x 2.5” Internal, 1 x Slim ODD
 RM23812: 12 x 3.5” Hot-swap
 RM23824: 24 x 2.5” Hot-swap, 2 x 2.5” Hot-swap (Rear, Option)
Storage Backplane
 RM23808: 3.5” 8-port 12Gbps, Mini-SAS HD
 RM23812: 3.5” 12-port 12Gbps, Mini-SAS HD, Passive or Active
 RM23824: 2.5” 8-port 12Gbps, Mini-SAS HD, 2.5” 16-port 12Gbps, Mini-SAS HD, Expander
 RM23824 (NVMe): 2.5” 8-port 12Gbps, Mini-SAS HD, 4-port Tri-mode,
2.5” 8-port PCIe Gen3, OCuLink
PSU Form Factor
 1+1 CRPS or Single 2U
Indicator
 1 x Power Status, 2 x LAN Activity, 1 x UID, 1 x System Alarm, 1 x HDD Status
Front Control
 1 x Power On/Off, 1 x UID, 1 x System Reset, 2 x USB3.0
System Security
 Intrusion Switch (option)
Cooling Fan
 80 x 25/38 mm (3, up to 4), Hot-swap/Non Hot-swap
Expansion Slot Opening
 7 x Low Profile or 3 x Full Height
Net Weight
 11.5 kg/25.33 lb
Gross Weight
 14.0 kg/30.84 lb
Cubic Feet
 3.30
Container Loading
 20': 200, 40': 460, 40'H: 506 (Single Packing)
