Edge/Edge Blanket Operating Principles
5-9
MAIN ELECTRICAL PANEL COMPONENTS
Schematic Description
IC1 Input Card - Start/Stop, Corner, Roller, Transfer, Upper Spreader signals
IC2 Input Card - Spread Home, Tail, Taut, Wall, Stain/Tear, Ironer signals
IC3 Input Card - Air pressure, Wall, Inlet, Crossbeam, Tail, Reject Enable signals
IC4 Input Card - 22VAC Circuit Monitor Points
MPC1 Machine Controller Board - Spread/Feed Control Circuit Board
PSC1 Power Supply - 5VDC, 24VDC Power Supplies, AC Detect
SC1 Speed Control - Inverters 1-4
OC1 Output Card - Control, Alarm, Sensor Blowoff, Spreader, Conveyor signals
OC2 Output Card - Inlet Conveyor, Clutch, Lower Spreader signals
OC3 Output Card - Transfer/Spread signals
OC4 Output Card - Spread, Air, Reject signals
OC5 Output Card - Spreader Speed, Ironer Speed signals
OC6 Output Card - Pacing Lights (option)--mounted on top of OC1 if included
