- 38 -
FNC code……Application function code, R/W……R: READ, W: WRITE
Reference
number
FNC
Code
R/W Data name
Setting range
(Communication
range)
Initial
value
Remarks
48012
48013
48014
48015
48016
48017
48019
48020
48021
48022
48023
48024
48026
48027
48028
48029
48030
48031
48032
48033
03
06
16
R
W
W
External signal
allocation
[First zone]
Terminal No.12
Terminal No.13
Terminal No.14
Terminal No.15
Terminal No.16
Terminal No.17
[Second zone]
Terminal No.19
Terminal No.20
Terminal No.21
Terminal No.22
Terminal No.23
Terminal No.24
[Third zone]
Terminal No.26
Terminal No.27
Terminal No.28
Terminal No.29
Terminal No.30
Terminal No.31
Terminal No.32
Terminal No.33
0000h to 020Dh
(0000h to 020Dh)
**00h
(Each
format)
･Function of terminal (Lower order 8
bits)
[DI] (External signal input)
00h = -- (no setting)
01h = RUN/STOP (RUN/STOP
operation)
02h = ADV (ADVANCE operation)
03h = RESET (RESET operation)
04h = WAIT (WAIT operation)
05h = FAST (FAST operation)
06h = PTN1 (Pattern No. selection
BCD_1)
07h = PTN2 (Pattern No. selection
BCD_2)
08h = PTN4 (Pattern No. selection
BCD_4)
09h = PTN8 (Pattern No. selection
BCD_8)
0Ah = PTN10 (Pattern No. selection
BCD_10)
0Bh = PTN20 (Pattern No. selection
BCD_20)
[DO] (External signal outnput)
00h = -- (no setting)
01h = TS1 (Time signal 1)
02h = TS2 (Time signal 2)
03h = TS3 (Time signal 3)
04h = TS4 (Time signal 4)
05h = TS5 (Time signal 5)
06h = TS6 (Time signal 6)
07h = TS7 (Time signal 7)
08h = TS8 (Time signal 8)
09h = RUN/STOP (RUN/STOP status
signal)
0Ah = ADV (ADVANCE status signal)
0Bh = RESET (RESET status signal)
0Ch = WAIT (WAIT status signal)
0Dh = END (END status signal)
･Type of terminal (Lower order 8 bits)
00h = -- (no terminal or other than
external signal input/output terminal)
01h = DI (External signal input
terminal)
02h = DO (External signal output
terminal)
*Type of terminal cannot be written.
*When type of terminal is other than
DI or DO, cannot be written.
