9-3-2. Response output of KP to the data request command (KP → PC)
Function Output format
① Real data
output
In KP3000,
PV, MV data
becomes the
dummy data.
(Note) PV, SV data up to 4 positions after the decimal point can be sent and if it exceeds 6 digits
including the decimal point, the digit in the lowest position is truncated.
② Mode 0
Execution
parameter output
In KP3000, all the
data except SV data
becomes a dummy
data.
STX △2, □□□□□□□□, □□□□□□□□, □□□□□□□□,
Execution target SV Execution P (dummy) Execution I (dummy)
□□□□□□□□, □□□□□□□□, □□□□□□□□,
Execution D (dummy) Execution AL1 (dummy) Execution AL2 (dummy)
□□□□□□□□, □□□□□□□□, □□□□□□□□,
Execution AL3 (dummy) Execution AL4 (dummy) Execution OL (dummy)
□□□□□□□□, □□□□□□□□, □□□□□□□□,
Execution OH (dummy) Execution variation limit Execution sensor correction
(dummy) (dummy)
□□□□□□□□, □□□□□□□□, □□□□□□□□,
Second P (dummy) Second I (dummy) Second D (dummy)
ETX BCC CR LF
③ Setting program
pattern data
output
[In case of reset
only]
In KP3000, all the
parameter No.
excluding TS
become the dummy
data.
(i) Step 0 output
STX △3, △1, □□, △0, □□□□□□□□, □, ETX BCC CR LF
Pattern No. Step No. Start SV 0= Start SV
1= Start PV
(ii) Step n output
STX △3, △2, □□, □□, □□□□□□□□, □□□, □□, □□,
Pattern No. Step No. SV Time.
Repeat count
△0= Repeat start step
△△= Un-set step
PID ALM OPL OSL TS1 TS2 TS3 TS4 TS5
No. No. No.
No. Waiting time No. (dummy) 0=ALL OFF
(dummy) (dummy) (dummy) (dummy) Real temperature compensation No. (dummy) 1=No.1
Sensor correction No. (dummy)
2= Repeat No.1
17=ALL ON
ETX BCC CR LF
STX △1, □□, □□, □, □□□□□□□□, □□□□□□□□,
Pattern
No.
Step No.
PV(dummy)
PV status: 0=Normal, 4=Hardware erro
r
0 in case of
resetting
SV9(Set value)
A
ll 9 digits in case of over range
□, □, □□□,□□ □, □□□□□□□□, □, □□□□□□□□
Time display system
1=Elapsed step
2=Elapsed pattern
3=Remaining step
4=Remaining pattern
ETX BCC CR LF
Time unit
T
ime
1=Minute
2= Hours
3= Days
MV1 (dummy)
MV2 (dummy)
It becomes the dummy data
It becomes the dummy data
□, □, □, □, □, □, □, □□, □□, □□, □□, □□,
