Page #68 background imageLoading...
Page #68 background image
- 65 -
Function Output format
In case of KP3000,
output at the time of
END becomes the
dummy data.
(iii) END step output
STX 3, 3, □□, □□, □□, □□□□□□, ETX BCC CR LF
Pattern No. Step No. Output in case of END (dummy)
Link destination
Pattern No.
0=No link
(iv) Repeat pattern output
STX 3, 6, □□□□□□□□, ETX BCC CR LF
Repeat count
Individual setting
parameter
output
KP sends the requested setting parameter.
Sending format is the same as individual parameter setting format in case of
setting from PC in KP. (See 9-3-5)
However as the number of digits of the data differ, see Appendix 1
Communication format list for the details.
Program pattern
setting status
output
STX 5, □□, □□, ETX BCC CR LF
Setting step count
0= Not set
Pattern No.
Device status
output
STX 6, □, □, □, □, □, □, □, □, □, ETX BCC CR LF
1=Controller
2=Setter
0=Setter
1=Full multi-input
2=4-wire type
Input
Output 1
1=61, 65 [EMF]
2=62
3=63 [Linear]
In the bracket ([ ])
in case of KP3000
Time unit
0=Hours/minutes
1=Minute/seconds
Select pattern
External drive
Time signal
Transmission
0=Does not exist
1=Exists
Output 2
0=None
1=61, 65
3=63
