- 66 -

Function Output format

⑦ Mode lock status

output

STX △7, □, □, □, □, □, □, □, □, □, □, ETX BCC CR LF

1 2 3 4 5 6 7 8

Mode 0

FNC key 0= Non lock

1=Lock

2=NoDisp

⑧ Status 1

Output

STX △8, □□, □□, □□, □□, □, □, □, □, □, □, □,

AL1 AL2 AL3 AL4 TS1 TS2 TS3 TS4 TS5

Time signal

0=OFF

1=ON

Error

Waiting time alarm

ETX BCC CR LF

In KP3000 everything except TS becomes the dummy data

⑨ Status 2

Output

STX △9, □, □, □, □, □, □, □, □, □, □, □, □,

RUN 0= M/S 0=Master

1=RUN 1=Slave

STOP 0= FNC key 0=Non lock

1=STOP LOCK 1=Lock

RESET 0= AT (dummy)

1=RESET

END 0= WAIT (dummy)

1=END

ADV 0= MAN2 (dummy)

1=ADV

MAN1 (dummy)

CONST (dummy)

ETX BCC CR LF

In KP3000 a part of the data becomes the dummy data.
