9-3-4. Program pattern setting (PC → KP) [At the time of resetting only] [Mode 2 lock]
Set field Set format
① Step 0
STX △3, △1, □□, ００, □□□□□□, □,ETX BCC CR LF
Pattern Step Start SV 0= Start SV
No.
No. 1=Start PV
In KP3000, set it to SV start.
② Step n
STX △3, △2, □□, □□, □□□□□□□, □□□, □□,
Pattern Step SV Time
No. No.
ETX BCC CR LF
When setting the relevant step for the first time, if time is set as "0" (000
hours/00 minutes, or 000 minutes/00 seconds) error code 41 may occur.
When setting the time as "0", set the time as 0 0
0 . 0 1 and after the pattern
setting is done, change the setting to 0 0
0 . 0 0 .
(Note) Delimiter of time hours/minutes, minutes/seconds is period.
③ END step
[Mode 2 lock]
[Mode 4 lock]
STX △3, △3, □□, □□, □□, □□□□□□, ETX BCC CR LF
Pattern Step Output in case of END
No. No.
0= Output 0
200= Fixed control
Link destination pattern No.
00=No link
In KP3000, mode 4 is locked using communication and 0 is set in END output.
④ Parameter No.
setting
STX △3, △4, □□, □□, □, □, □, □, □, □, □,
Pattern Step PID ALM OPL OSL Waiting time number
No. No. No. No No. No.
□□, □□, □□, □□, □□, ETX BCC CR LF
TS1 TS2 TS3 TS4 TS5
00=ALL OFF *Set 00 in case of no TS.
01=No.1
02=Repeat No.1
16=Repeat No.8
99=ALL ON
In KP3000, set 0, except for TS.
⑤ Repeat
step
STX △3, △5, □□, □□, □□, □□, ETX BCC CR LF
Pattern Repeat count
No. End step 1 to 99=Count
Starting step 00=Cancel repeat
Starting < End, always
⑥ Repeat
pattern
STX △3, △6, □□□□, ETX BCC CR LF
Repeat count
⑦ Copy
pattern
STX △3, △7, □□, □□, ETX BCC CR LF
Copy destination pattern No.
Copy source pattern No.
⑧ Clear
pattern
STX △3, △8, □□, ETX BCC CR LF
00=Clear ALL
1 to 19=Clear pattern unit
Real temperature compensation
No. (0=OFF)
Sensor correction No.
