6-4. Setting communication protocol (COM PROTOCOL)
① 'COM PROTOCOL' is displayed using
 key.
② Select communication protocol using
  key and register it using  key.
Selection Communication Protocol Initial value
MODBUS (RTU) MODBUS protocol RTU mode
MODBUS (ASCII) MODBUS protocol ASCII mode
PRIVATE PRIVATE protocol
MODBUS (RTU)
Ú If communication protocol is changed, communication character changes to initial value.
6-5. Setting communication character (COM CHARACTER)
① 'COM CHARACTER' is displayed using  key.
② Select communication character using   key and register it using  key.
[MODBUS RTU]
Selection Bit length Parity Stop bit Initial value
8BIT/NON/STOP1 1
8BIT/NON/STOP2
None
2
8BIT/EVEN/STOP1 1
8BIT/EVEN/STOP2
Even
2
8BIT/ODD/STOP1 1
8BIT/ODD/STOP2
8bit
Odd
2
8BIT/NON/STOP1
[MODBUS ASCII]
Selection Bit length Parity Stop bit Initial value
7BIT/EVEN/STOP1 1
7BIT/EVEN/STOP2
Even
2
7BIT/ODD/STOP1 1
7BIT/ODD/STOP2
7bit
Odd
2
8BIT/NON/STOP1 1
8BIT/NON/STOP2
None
2
8BIT/EVEN/STOP1 1
8BIT/EVEN/STOP2
Even
2
8BIT/ODD/STOP1 1
8BIT/ODD/STOP2
8bit
Odd
2
7BIT/EVEN/STOP1
