Chino KP3000 - 9-4. Positive response and negative response; 9-4-1. Positive response; 9-4-2. Negative response; 9-4-3. Error code

- 70 -
9-4. Positive response and negative response
9-4-1. Positive response
ACK=06H
9-4-2. Negative response
NAK=15H
* Do not apply STX, ETX, BCC to ACK/NAK.
9-4-3. Error code
Code Error type Contents
△1
Framing
△2
Over run
△3
Parity
△4
Check sum
△5
Lock/non lock
･During non lock, high order was confirmed and command
was sent.
10
Format
･Fast communication code error
11
〃 ･Second communication code error
12
〃 ･Third onwards communication code error
14
〃 ･ETX error (No ETX)
15
〃 ･Excess reception buffer
16
Numeric value
･Cannot recognize as numerals.
20
Data
･Undefined numeric value is received. (Numeric value is
out of range)
21
〃 ･L/H error (Greater and smaller relation is reversed)
22
〃 ･SV RANG error (It is set out of SV RANG)
23
〃 ･SV scope error
24
〃 ･Z/S error (Greater and smaller relation is reversed)
25
〃 ･Linear range error
30
Program drive
･ADV, STOP was done during reset.
31
〃 ･Pattern was selected during STOP.
32
〃 ･Pattern was selected during RUN.
33
〃 ･RUN, STOP, ADV, Pattern were selected during END.
34
〃 ･RUN, STOP, ADV, RESET was done during CONST.
35
External drive OP
･Program drive was RUN, STOP, ADV, RESET during KEY
or EXT
(Note) △=Space
ACK CR LF
NAK Error Code CR LF
