Chino KP3000 User Manual

- 32 -
8-7. Reference table
8-7-1. Analog setting value
① Setup parameter 1
FNC code……Application function code, R/W……R: READ, W: WRITE
Reference
number
FNC
Code
R/W Data name
Setting range
(Communication
range)
Initial value Remarks
40008
03
06
16
R
W
W
SV decimal
point
0 to 4
(0 to 4)
1
(Decimal
1-digit)
40009
40010
03
06
16
R
W
W
SV range
‘Lower limit’
‘Higher limit’
-19999 to 30000
(-19999 to
30000)
0.0
2000.0
･Decimal point position = SV
decimal point
･Write when lower limit ≦
higher limit.
40020
03
06
16
R
W
W
SV decimal
point
for display
0 to 4
(0 to 4)
1
(Decimal
1-digit)
SV decimal point position of
upper display
② Setup parameter 2
FNC code……Application function code, R/W……R: READ, W: WRITE
Reference
number
FNC
Code
R/W Data name
Setting range
(Communication
range)
Initial value Remarks
40052
40053
03
06
16
R
W
W
SV scale
'zero'
'span'
-19999 to 30000
(-19999 to 30000)
0.0
2000.0
Decimal point position = SV
decimal point
40092
03
06
16
R
W
W
Operation
when starting
the power
supply
0/1
(0/1)
0
(CONTINUE)
0= CONTINUE (Status before
power cut off)
1= READY (Status of program
operation reset)
③ 1 type parameter
FNC code……Application function code, R/W……R: READ, W: WRITE
Reference
number
FNC
Code
R/W Data name
Setting range
(Communication
range)
Initial value Remarks
40147
03
06
16
R
W
W
SV correction
-19999 to 20000
(-19999 to 20000)
0
Decimal point position : SV
decimal point + 1-digit (Max.
4-digit)
④ Execution parameter & Specific parameter
FNC code……Application function code, R/W……R: READ, W: WRITE
Reference
number
FNC
Code
R/W Data name
Setting range
(Communication
range)
Initial
value
Remarks
40151 03 R
[Upper display]
SV
(setting value)
Within the range
of SV limit
(Within the range
of SV limit)
0.0
SV value (SV during program
operation)
･Decimal point position = SV
decimal point
･No WRITE
