Chino KP3000 User Manual

- 63 -
9-3. Communication format
Precautions
When transfer the parameter from old instrument to this instrument,
check the setting range of each parameter because some parameters of
setting range (for example, SV (setting value), alarm value etc.) is
different from old instrument.
9-3-1. Data request command (PC → KP)
Command name Command format Status
① Real data
request
STX △1, △1, ETX BCC CR LF
(DF)
Current data
request
② Execution
parameter
request
STX △1, △2, ETX BCC CR LF
(EF)
Mode 0 execution
parameter request
③ Setting program
pattern data
request
[In case of resetting
only]
STX △1, △3, □□, □□, ETX BCC CR LF
Step No.
Pattern No.
Repeat pattern in case of 00
Request data
Program pattern
data request
Data request for
each step
④ Individual setting
parameter
request
STX △1, △4, □□, □□, ETX BCC CR LF
1 to 8=Parameter No.
When parameter is
8 types
When 91 to 98=PID9
When 1=Parameter
is 1 type
Parameter type No.*1
*1 parameter type No. is a number given to setting
parameter and is indicated in section 9-3-5.
Data request by
specifying 1
setting parameter
⑤ Program pattern
setting status
request
STX △1, △5, □□, ETX BCC CR LF
Pattern No.(1 to 30)
Pattern setting
status request
⑥ Device status
request
STX △1, △6, ETX BCC CR LF
(20)
Request
configuration
status of the
device
⑦ Mode lock
status request
STX △1, △7, ETX BCC CR LF
(30)
Request each
mode lock status
⑧ Status 1
request
STX △1, △8, ETX BCC CR LF
(40)
Request the status
of alarm, error,
time signal
⑨ Status 2
request
STX △1, △9, ETX BCC CR LF
(50)
Request the status
of program
operation
(Note) △=Space
