Chino KP3000 User Manual

- 52 -
FNC code……Application function code, R/W……R: READ, W: WRIT
E
Reference
number
FNC
code
R/W Data name Detailed explanation
30143 04 R Abnormality status
0= No error
1= Error activation (activating scale correction error)
30144 04 R Time signal status
0= Time signal OFF (extinction [TS1] or [TS2] or …..
or [TS8])
1= Time signal ON (lighting [TS1] or [TS2] or ….. or
[TS8])
* READ after relating bit 0 to 7 of 16 bits data to time
signal 1 to 8.
Low order 8 bits
8-7-3. Digital input data (READ only)
System abnormality status
FNC code……Application function code, R/W……R: READ, W: WRITE
Reference
number
FNC
code
R/W Data name
Detailed explanation
10005 02 R System abnormality
0= Normal
1= Correction data abnormality activation
TS2 TS4TS6 TS5 TS3 TS1 TS8
TS7
4 3 2 1 0
bit7 6 5
