Table 1-1 Description of the Front Panel
Item
Symbol
Description
1
Display: The LCD is to display configuration, output setup, and
measurement results.
2
Indicator LED: "OUT" and "SHIFT", for showing activation of
output and shift mode, are available which are located on the
keypad area next to the corresponding keys.
3


----------or----------
PAGE 
PAGE 
Cursor moving keys: These two keys are to move the cursor
to different directions respectively. In normal mode, pressing
any of these two keys will change the place of the cursor.
Under shift mode, these keys enable the LCD display to change
to last page or next page if there are  or  patterns in
right-down side of display.
4
PAGE/EXIT
----------- or ---------
SAVE
PAGE or EXIT command key: Pressing this key will make the
LCD display switching between MAIN PAGE and CHOICE
PAGE. Or change to CHOICE PAGE in each functional list.
Under shift mode, pressing this key on MAIN PAGE, the uses
can save the output setting (see
3.8.1). If pressing the key on
CHOICE PAGE, the user can save system data (see 3.8.2).
5
 / -
---------- or -----------
RECALL
Backspace and Minus command key: Pressing this key will
erase the keyin number. Or it may show " - ", if no number is
in front of cursor. Under shift mode, pressing the key on MAIN
PAGE, the user can recall the output setting (see
3.8.1). If
pressing the key on CHOICE PAGE, the user can recall
system data (see 3.8.2).
6
OUT/QUIT
OUT/QUIT command key: Pressing this key may enable the ac
source output voltage or quit the output voltage.
7
SHIFT
Shift mode selection key: Pressing this key will switch the ac
source from normal operational mode to the shift mode.
8
0 to 9 , and
•
------------ or ----------
HELP
Numeric and decimal keys: The user can program numeric
data by pressing the digital keys and the decimal key. Under
shift mode, pressing
•
acts the HELP function. The LCD
display will show more information about cursor locating place.
9
ENTER
ENTER key: It is to confirm the setting of parameters.
10
RPG: The user can input programming data or options by
turning the RPG to the desired ones.
11
Main power switch: It is to power on or off.
