Chroma 6330 Series User Manual

Programmable DC Electronic Load 6310 Series Operation & Programming Manual
MODEL 63307(30W,250W) 63306
POWER
30W 30W 250W 60W 600W
CURRENT
0∼5A 0∼4A 0∼40A 0∼12A 0∼120A
VOLTAGE
1∼80V 1∼80V
MIN. OPERATING
VOLTAGE (DC)
1.0V at 5A 1.0V at 4A 1.0V at 40A 1.0V at 12A 1.0V at 120A
CC MODE Range
0∼5A 0∼4A 0∼40A 0∼12A 0∼120A
Resolution
1.25mA 1mA 10mA 3mA 30mA
Accuracy
0.1%+0.1%F.S. 0.1%+0.1%F.S. 0.1%+0.2%F.S. 0.1%+0.1%F.S. 0.1%+0.2%F.S.
CR MODE Range
0.3Ω∼1.2KΩ (30W/16V)
15Ω∼60KΩ (30W/16~80V)
0.375Ω∼150Ω (250W/16V)
1.875Ω∼7.5KΩ
(250W/16~80V)
12.5mΩ∼50Ω (600W/16V)
0.625Ω∼2.5KΩ (600W/16~80V)
Resolution
12 bits 12 bits 12 bits
Accuracy
12KΩ : 0.1 mho +0.2%
60KΩ : 0.01
mho +0.1%
150Ω : 0.1
mho +0.2%
7.5KΩ : 0.01
mho +0.1%
50Ω : 0.4
mho +0.5%
2.5KΩ : 0.04
mho +0.2%
CV MODE Range
1∼80V 1∼80V
Resolution
20mV 20mV
Accuracy
0.05%±0.1%F.S. 0.05%±0.1%F.S.
DYNAMIC MODE
DYNAMIC MODE
C.C. MODE C.C. MODE
T1 & T2 0.025mS - 50mS/Res: 5uS
0.1mS - 500mS/Res: 25uS
10mS – 50S/Res: 2.5mS
0.025mS - 50mS/Res: 5uS
0.1mS - 500mS/Res: 25uS
10mS – 50S/Res: 2.5mS
Accuracy
1μS /1mS+100ppm 1μS /1mS+100ppm
Slew Rate
0.8∼200mA/μS 0.64∼160mA/μS6.4∼1600mA/μS 0.002∼0.5A/μS 0.02∼5A/μS
Resolution
0.8mA/μS 0.64mA/μS 6.4mA/μS 0.002A/μS 0.02A/μS
Current
0∼5A 0∼4A 0∼40A 0∼12A 0∼120A
Resolution 1.25mA 1mA 10mA 3mA 30mA
Current Accuracy 0.4% F.S. 0.4% F.S.
MEASUREMENT SECTION
VOLTAGE READ
BACK
Range
0∼16V 0∼80V 0∼16V 0∼80V 0∼16V 0∼80V
Resolution 0.5mV 2.5mV 0.5mV 2.5mV 0.5mV 2.5mV
Accuracy 0.05%+0.05% F.S. 0.05%+0.05% F.S.
CURRENT READ
BACK
Range
0∼5A 0∼4A 0∼40A 0∼12A 0∼120A
Resolution 0.15625mA 0.125mA 1.25mA 0.375mA 3.75mA
Accuracy 0.1%+0.1% F.S. 0.1%+0.1% F.S.
PROTECTIVE SECTION
Over Power Protection
≒31.2W ≒31.2W ≒260W ≒62.4W ≒624W
Over Current Protection
≒5.1A ≒4.08A ≒40.8A ≒12.24A ≒122.4A
Over Temperature Protection
≒85°C ≒85°C
Over Voltage Protection
≒81.6V ≒81.6V
GENERAL
SHORT CIRCUIT
Current (CC) - -
≒40A
-
≒120A
Voltage (CV) - - 0V - 0V
Resistance (CR) - - -
≒0.0375Ω
-
≒0.0125Ω
INPUT RESISTANCE
(LOAD OFF)
100KΩ (Typical) 100KΩ (Typical)
SIZE
81(W)× 172(H)×495(D) 162(W)× 172(H)×495(D)
WEIGHT (Approx.)
4.2Kg 8.4Kg
EMC & SAFETY
CE CE
1-6
