Local Operation
CONF To select configuration data for editing.
Entry keys
▲ ▼ They let you scroll through choices in a parameter list that is
applied to a specific command. Parameter lists are circular.
You can return to the start position by pressing either of
the keys continuously.
ON/OFF It toggles the Electronic Load output between on and off states
if channel SYNC RUN is set to on.
ENTER It executes the entered value or the parameter of accessed
command. The parameters you have entered with other keys
are displayed but not entered into the Load until you press this
key. Before pressing ENTER you can change or abort
anything entered into the display beforehand.
SHIFT It enables a shifted key to function (LOCK, SYS). When in
remote control state, this key acts as a local key.
0 - 9 They are used for entering numeric values.
. It is a decimal point.
4.2.1 Selecting the Channel
The CHAN key is used to select one of the channels for local control. See channel number
in section 2.3.1. To edit the channel settings, you must select a channel first. If the channel
does not exist, it cannot be selected. If no module is installed in the mainframe, the display
will show DUMMY CHANNEL. When you press CHAN, the channel number you want to
select will automatically increase to the next existing channel. The mainframe will scan the
module type at power-on and memorize it for channel editing.
4.2.2 Setting the Operation Mode
The MODE key and ▲, ▼ keys are used to select modes of channels for local control.
Press MODE to display the selected channel that is in active mode. The active mode can be
changed by ▲ or ▼ key followed by the ENTER key. The sequence of mode selection
after pressing ▼ key is as follows:
CCL -> CCH -> CCDL -> CCDH -> CRL -> CRH -> CV go back to CCL.
Press ENTER key to select mode and confirm the setting.
4-3
