Programmable DC Electronic Load 6310 Series Operation & Programming Manual
boundary when the SPEC TEST is ON, and the LED, GO/NG, is lit on the module panel.
To set specifications for module, you must press MODE, ENTER and then SPEC key to go to
mode for editing. In other operation modes, press SPEC to enable/disable the SPEC TEST
function. The SPEC TEST ON/OFF function is global that means all modules installed on
the Mainframe will do GO/NG comparison. The specification unit of CC, CR mode is volt
while CV mode is current. There are three levels for each mode: CENTER, HIGH and
LOW. The CENTER level must be set by the value of channel input reference level. The
HIGH and LOW levels can be set by the value or percentage selected in configuration SPEC.
ENTRY MODE. The HIGH/LOW percentage range is from 0 to 100%.
Press MODE, ENTER, SPEC to set the specifications of CC mode. Press 5, ENTER to set
CENTER level 5V.
VOLTAGE SPEC.
CENTER: 5.0000V
Press 5, ENTER to set HIGH level 5%.
VOLTAGE SPEC.
HIGH PCet: 5.0%
Press 5, ENTER to set LOW level 5%.
VOLTAGE SPEC.
LOW PCet: 5.0%
The default setting of HIGH and LOW is 100%. The CENTER value is half of the range.
For selection of the specifications set by Value or Percentage please refer to 4.2.6.
4.2.6 Setting the Configuration
The Electronic Load provides useful features such as Von point, Current limit, Sync run, etc.
To use these powerful features, you must set relevant parameters in accordance with
application needs for configuration setup. This procedure is needed for initial setup only.
The configuration of each channel is stored separately in the EEPROM of Mainframe. To
set configuration you need to press CONF.
Set the voltage range of CC mode. There are two voltage ranges for CC mode. High
range is for high voltage and low range for low voltage so as to get better voltage resolution.
The default setting of Vrange is HIGH.
CC Vrange Select
1:HIGH 2=LOW
Set Von point. Von is the conduction voltage level when the Electronic Load starts to sink
current and the UUT output reaches the Von voltage. The default setting for Von voltage is
1V.
4-10
