Programmable DC Electronic Load 6310 Series Operation & Programming Manual
2. Setting the Sequence P/F Delay Time
The sequence Pass/Failure delay time let you set the delay time for P/F checking when
load condition changes. The failure status of the sequence will latch when a program is
executed. It means that any failure will be memorized even when the UUT becomes
stable within the specifications later. The range of P/F delay time is from 0 to 60
seconds. Press 1, ENTER to set the sequence P/F delay time for 1 second. The
default setting is 0 second.
SEQ. P/F DELAY
TIME: 1.0Sec
Setting the Sequence ON/OFF Time
The sequence ON/OFF time controls the Load input ON/OFF when the program
sequence is executed. The range of ON/OFF time is from 0 to 60 seconds.
SEQ. ON TIME
TIME: 1.0Sec
Press 0, ENTER keys to set OFF time to 0 second. The default setting is 0 second for
OFF time.
SEQ. OFF TIME
TIME: 0.0Sec
Setting the Sequence Mode
There are three modes to control the sequence execution.
SKIP: Skip the sequence. Load will not change input status.
AUTO: Use ON/OFF time to control Load input on/off. When ON/OFF time
passes, the Load will get to the next sequence automatically.
MANUAL: Use ▲ or ▼ or number 0 to 9 to control the execution sequence.
Pressing number key lets you select a random sequence number for
execution. Pressing 0 will go to sequence 10.
Press 2, ENTER keys to set sequence 1 to manual mode. You must set ten sequence
settings for one program. The default setting is SKIP.
SEQ 1: SKIP=0
AUTO=1 MANUAL=2
Setting the Short Channel
When the sequence mode is not SKIP, you must set the short channel & time. The
short channel is selected as active channel. For selection of short channel, press
number 1 to 8 to enable or disable the corresponding module short function.
SEQ. 1 SHORT CH.
1 3 5 6 7 8
4-8
