The SHORT key enables Load to simulate short function. Its LED will be on when the
short function of Load is enabled. It operates only when the Load input is enabled. It
will not respond if Load input is not enabled.
The LOAD key controls the on/off of Load module input. Its LED will be on when the
Load input is enabled.
6. Vsense Connectors
These two connectors are Vsense measurement input. Refer to section 2.5.2 for remote
sense connections.
7. Rotary Knob
The knob changes the level when the Load input is enabled. Rotating the knob
clockwise will increase the level whereas counterclockwise decrease the level. When
you change the Load level with knob, the setting of Mainframe will not change. The
changed Load level will hold unless the same setting is changed on Mainframe.
8. Load Terminals
They are input connectors of Load for connecting to the UUT. Each of them can carry
40 Amps at most. If the current is over 40 Amps, you must connect two or more
terminals for load connection. The PLUS (+) must be connected to the UUT high
potential. Refer to section 2.5.1 for load input connection.
Examples
Following examples illustrate how to operate the module in CC mode.
1. Select Level1 (A) and Level2 (B)
There are two levels of each mode for you to select in static function. The level1 (A)
and level2 (B) can be selected through A/B key. Press A/B key to select current level1
or level2. When level1 (A) is selected, the LED of A/B key will be active. Press this
key again to select level2 (B), and the LED will be inactive.
2. Select Dynamic Function
There are two functions for CC mode: STATIC and DYNAmic. The two functions can
be selected through STATIC/DYNA key. Press STATIC/DYNA key to select Dynamic
function. Press this key again to select static function. When Dynamic function is
selected, the LED of DYNA will be active.
3. Short the Load Input
The Load can simulate a short circuit across the input. The short circuit will be enabled
when SHORT is pressed, and Load input is active (on). If the input is shorted, the LED
of short will be active. The SHORT key can be set in configuration to toggle on/off
mode, or active by pressing.
4. Load Input On/Off
The input can be toggled on or off by pressing LOAD. When the input is turned on, the
load LED will be active.
