See “Installing an Alarm Cable (Optional)” on page 2-25 for a procedure.
Synchronization Cable
The synchronization cable is connected to the SYNC port on the faceplate of
the 5160 system. This port is used for the BITS interface, 1PPS or Time of Day
and has an RJ-45 jack.
Note: The BITS interface can be configured to be either BITS-IN or
BITS-OUT. It cannot do both BITS-IN and BITS-OUT simultaneously.
Ciena offers two optional cables for this interface that are 6 foot long shielded
cables with the following specifications:
• 100 Ohm cable with RJ-45 connectors is cable 170-0083-900
• 120 Ohm cable with RJ-45 connectors is cable 170-0084-900
One end has a shielded RJ-45 connector and the other end is un-terminated.
When using this cable, the shield of the un-terminated end must be
connected.
Table 2-2
5160 Alarm Port Pin Assignments
Pin # Lead Color Pin # Lead Color
1 Alarm sense 15 WH/BL 14 Alarm sense return 4 RD/OR
2 Alarm sense 13 BL/WH 15 Alarm sense return 3 OR/RD
3 Alarm sense 11 WH/OR 16 Alarm sense return 2 RD/GR
4 Alarm sense 9 OR/WH 17 Alarm sense return 1 GR/RD
5 Alarm sense 7 WH/GR 18 Frame ground No connect
6 Alarm sense 5 GR/WH 19 Alarm sense 16 RD/BR
7 Alarm sense 3 WH/BR 20 Alarm sense 14 BR/RD
8 Alarm sense 1 BR/WH 21 Alarm sense 12 RD/SL
9 Frame ground No connect 22 Alarm sense 10 SL/RD
10 Alarm sense return 8 WH/SL 23 Alarm sense 8 BK/BL
11 Alarm sense return 7 SL/WH 24 Alarm sense 6 BL/BK
12 Alarm sense return 6 RD/BL 25 Alarm sense 4 BK/OR
13 Alarm sense return 5 BL/RD 26 Alarm sense 2 OR/BK
