Fiber Optic Cables
There are two types of ports on the 5160 that accept pluggable optics:
• 1/10 Gigabit Ethernet ports which support SFP and SFP+ optics
• 100/1000 Mbps Ethernet ports which support SFP optics
The SFP/SFP+ pluggables in the 5160 allow you to select the port speed,
wavelength, etc to match the device on the terminating end. See
“Transceivers” on page 2-9 for more information about the transceivers, and
their installation.
The SFP/SFP+ ports will require optical cables. You will need to know the
specification of the optic to select the appropriate cable.
Do not remove the dust cover until immediately prior to mating the connectors.
For best results, prior to mating the Fiber optic connectors clean both the port
and the connector with a lint free cloth moistened with alcohol. If available, the
connectors should also be blown dry using canned, compressed air. Insert the
connector into the port on the device until you hear a clicking sound.
Ethernet Cables
The following ports on the 5160 use Ethernet cables and have standard RJ-45
jacks:
• MGMT 10/100/1000 Port
• Console Port
Ciena requires the use of Cat 5 STP cables or better for the Management
ports. These interfaces are classified as intra-building only. The cable shield
must be terminated at both ends.
To install an Ethernet cable, insert the connector into the port on the device
until you hear a clicking sound. Insert the tail end of the cable into the port on
the terminating device.
