5160 Service Aggregation Switch Hardware Installation and Start-up Manual
009-3207-001 Standard Revision A
Copyright
©
2013 Ciena
®
Corporation September 2013
Technical Specifications 6-
This chapter summarizes the technical specifications for 5160.
Table 6-1
Specifications
Feature Specification
Fault Tolerance • Redundant power supplies
Power Rating • AC Input Power 100 to 240 VAC, 50/60 Hz, 2.8 Amps maximum
• DC Input Power -/+24 VDC. -/+36 VDC, or -/+ 48 VDC
Minimum 20 VDC, Maximum 60 VDC,
12 Amps maximum
Power Consumption • Typical Power Consumption 113 W
• Maximum Power
Consumption
175 W
Connector Types • NNI / UNI Ports (1/10 Gigabit) SFP and SFP+ optics
• Local Management Port
(10/100/1000 Mbps)
RJ-45
• Console Port RJ-45 (EIA-561)
• Sync Port (BITS/Time of Day) RJ-45 (Custom cable)
• 1 PPS Port 50 Ohm SMB interface
• 10 MHz Port 50 Ohm SMB interface
• Alarm 26-pin D-sub
Physical • Chassis Dimensions 4.4 cm H x 44.4 cm W x 25.4 cm D
(1.75 in H x 17.5 in W x 10 in D)
• Rack Unit Height 1 RU
