Procedure 2-4
Installing an AC Power Supply
Step Action
1 Remove the power supply module(s) from the packaging and inspect them
for damage.
2 Do one of the following:
• If a single power supply module is being installed, slide the power supply
module into slot PSA. Ensure that the PSB slot is covered by a filler plate.
(By default, the chassis has a filler plate installed over PSB.) See Figure
2-2 on page 2-6.
• If redundant power supply modules are being installed, remove the filler
plate covering PSB, then slide the power supply modules into slots PSA
and PSB. See Figure 2-2 on page 2-6.
3 Using a Phillips screwdriver, secure the module in place using the captive
hold down screw on the right of the module.
4 Plug the AC power cord into the receptacle on the front of the power supply
module. Snap the bail lock latch up over the boot of the cable to lock the cable
into place.
Note: After it is installed, the power cord will be dressed to the right, across
the front of the power supply. It is not appropriate to dress the power cord to
the left, across the front of the 5160 chassis.
5 If two power supplies are installed, repeat step 4. If only one power supply is
installed, proceed to step 6
6 Dress the power cable(s) to the right, through the cable support bracket at the
right of the chassis.
7 Plug the other end of the power cord(s) into a power source.
The power supplies will turn on.
WARNING: The AC socket outlet shall be installed near the equipment and
shall be easily accessible.
