Turning Up the System 3-7
5160 Service Aggregation Switch Hardware Installation and Start-up Manual
009-3207-001 Standard Revision A
Copyright
©
2013 Ciena
®
Corporation September 2013
Procedure 3-1
Logging in through the Serial Console Port
Step Action
1 Ensure that the chassis is properly rack-mounted, grounded, and installed.
2 Connect a terminal or PC running terminal emulation software to the serial
console port using the recommended cable.
Note: The serial console port does not support connectivity to a modem.
3 If using a PC, launch the terminal emulation software.
4 At the prompt, configure the connected terminal with the following settings:
Character size = 8
Parity = None
Stop Bit = 1
Baud Rate = 9600 bps
Control = None
5 When the Hyper Terminal prompt is displayed, press Enter and the login
prompt is displayed. Enter the default user name and password.
username = su
password = wwp
You have logged in to the system.
