43
The following are seng descripons, sengs opons and default values for the BATTERY LVD sengs (Table 3.4.6).
The following graphic (Image 3.4.26) depicts the transion when the baery voltage enters and exits the low
baery state.
Time
LOW LEVEL
Events
BATTERY
VOLTAGE
OK LEVEL
EXIT LOW
BATTERY STATE
ENTER LOW
BATTERY STATE
Table 3.4.6 · BATTERY LVD seng descripons, opons and default values
Image 3.4.26 · BATTERY LVD
SETTING DESCRIPTION
OPTIONS
DEFAULT
OK LEVEL
Threshold for baery voltage, in millivolts,
that the baery voltage must reach or go
above before the LOW BATTERY alarm state
can be cleared
Range Value
12500Min 10000
Max 30000
LOW LEVEL
Threshold for baery voltage, in millivolts,
that if the baery voltage reaches or goes
below the system transions to the LOW
BATTERY alarm state
Range Value
11500Min 10000
Max 25000
