Cimarron ARCONTROL BMS - Page 74

72
Table 3.5.2 · MODBUS register map - variable registers
REGISTER
NUMBER
NAME
DESCRIPTION
DATA
TYPE
READ
or
WRITE
237 BMS MODULE LOCKOUT TYPE
The BMS Module lockout types register reports all
the current lockouts or faults in the BMS Module
as the summaon of the values for the individual
lockout codes shown in the table below:
UINT16 R
Value Lockout
1 BIST
2 High Temperature
4 Fuel Means Fault
8 Recycle Lockout
16
Thermocouple Open Fault
32 Thermocouple Wiring Fault
64 Thermocouple Dierence
128 Flame Sense Fault
256 EEPROM Fault
512 ADC Fault
1024
Communicaon Lost Lockout
Example: If the system detects an ADC fault and
thermocouple goes open this register would report
512 + 16 = 528.
Range Value
Min 0
Max 65535
