Chapter 1
Understanding the Barcode Scanne
r
1.11 NEGATIVE BARCODES
Normally, barcodes are printed with the color of
the bars darker than
that of the spaces.
But for negative barcodes, they are printed in
the opposite sense just like negative films.
The spaces of negative barcodes are printed
with a color darker than
that of the bars.
You can configure the s
canner to be
able to read negative barcodes.
Enable
*Disable
