Circutor CVMk Series User Manual

----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 59
Registers of the CVMk electrical parameters :
VARIABLE REGISTERS VARIABLE REGISTERS
DECIMAL HEXA-
DECIMAL
DECIMAL HEXA-
DECIMAL
DATE / HOUR
*NOTE 1
0 - 1 00 - 01
Vav III N
38 - 39 26 - 27
V 1
2 - 3 02 - 03
mAav III
40 - 41 28 - 29
mA 1
4 - 5 04 - 05
W III
42 - 43 2A - 2B
W 1
6 - 7 06 - 07
varL III
44 - 45 2C - 2D
varL 1
8 - 9 08 - 09
varC III
46 - 47 2E - 2F
varC 1
10 - 11 0A - 0B
PF III
48 - 49 30 - 31
PF 1
12 - 13 0C - 0D
Hz (x10)
50 - 51 32 - 33
V 2
14 - 15 0E - 0F
VA III
52 - 53 34 -35
mA 2
16 - 17 10 - 11
V 12
54 - 55 36 - 37
W 2
18 - 19 12 - 13
V 23
56 - 57 38 - 39
varL 2
20 - 21 14 - 15
V 31
58 - 59 3A - 3B
varC 2
22 - 23 16 - 17
Vav III
60 - 61 3C -3D
PF 2
24 - 25 18 - 19
+ Wh - TARIFF 1
62 - 63 3E - 3F
V 3
26 - 27 1A - 1B
+ varh L -TAR. 1
64 - 65 40 - 41
mA 3
28 - 29 1C - 1D
+ varh C -TAR. 1
66 - 67 42 - 43
W 3
30 - 31 1E - 1F
Pd (last period )
68 - 69 44 - 45
varL 3
32 - 33 20 - 21
- Wh TARIFF 1
70 - 71 46 - 47
varC 3
34 - 35 22 - 23
- varh L TAR. 1
72 - 73 48 - 49
PF 3
36 - 37 24 - 25
- varh C TAR. 1
74 - 75 4A- 4B
