3-64
Cisco Aironet 1552 Series for Hazardous Locations Installation Guide
Chapter 3 Installing the 1552 Series Access Points in Hazardous Locations
Installation Details for the 1552SA and 1552SD Access Point
• Eight screws (#2-56 x .31 in) to attach the reels
• Two screws (#4-40 x .25 in) to attach the bracket
• One grommet
• One port adapter (5/8-24 to 1/2-14 NPT).
Note The adapter in this kit is EX compliant with the 1552S models.
The installation may require the use of junction boxes which have Ex certifications. Cisco does not
supply these, but recommends either the GRT50 or ERT50 models as shown in Figure 3-14.
Figure 3-14 Junction Boxes
Note The SFP module is a separate orderable item. Refer to the ordering guide for applicable SFP options.
Warning
Class 1 laser product.
Statement 1008
Note You need a customer-supplied outdoor-rated fiber-optic cable with an LC connector. The cable diameter
must less than 0.40 in. (10.0 mm). The diameter of the sheathing surrounding each individual fiber must
be less than 0.040 in. (1.0 mm).
