7-21
Cisco TelePresence System 3200
OL-14521-01
Chapter 7 Building the Second Row Table Assembly
Parts List
Figure 7-19 Tabletop Section 4 (Section 3)
Step 20 Place the left tabletop section 5 (section 7) on the table assembly and join it to table section 3 (section
6) using either the spline or biscuits, then use the draw bolts to join the sections.
204113
39
40
17
57
4(3)
