7-33
Cisco TelePresence System 3200
OL-14521-01
Chapter 7 Building the Second Row Table Assembly
Parts List
Figure 7-31 Panel End Braces, Table Leg, Right Tabletop End and Table Section 5 (Section 2)
Step 32 Attach the privacy panel alignment bracket to the underside of table section 1 (section 5).
Figure 7-32 Section 1 (Section 5) Privacy Panel Alignment Bracket
Step 33 Attach the privacy panel alignment bracket to the underside of table section 2 (section 4).
35
35
35
21
204124
35
22
204125
