9-5
Cisco TelePresence System 3200
OL-14521-01
Chapter 9 Routing Power and Signal Cables
Power Requirements for the Cisco TelePresence 3200
Step 3 Attach the table assembly PDU attachment to the center privacy panel.
Figure 9-3 Table assembly PDU attachment to the center Privacy panel
Note The PDU power cable should extend from the right side.
1
201184
