3-7
Cisco TelePresence System 3200
OL-14521-01
Chapter 3 Mounting and Leveling the Plasma Displays
Purpose of Leveling the Plasma displays
Figure 3-6 Level the Plasma displays along the X and Y axes
Caution Do not place the level against the Plasma display screen. Place the level against the Plasma display bezel.
Step 7 Align the edges of Plasma displays
The gap between Plasma displays should be uniformly even from the top edge of the Plasma display to
the bottom edge. You should try to make the gap as small as possible.
201116
