Chapter 5 Building the Lighting Assembly
Parts List
Step 2 Attach the left and right outer Support brackets (from Figure 5-1) to the horizontal bar on the left and
right Display structures.
Figure 5-2 Left and Right outer Support brackets (from Figure 5-1)
Note Use any of the six brackets that you assembled in Step 1. There is no physical difference between
the outer and inner Support brackets in Figure 5-1.
