5-13
Cisco TelePresence System 3200
OL-14521-01
Chapter 5 Building the Lighting Assembly
Parts List
Step 11 Attach the two center Metal Trim panels.
Figure 5-11 Two center Metal Trim panels
12
9
201135
31
