5-22
Cisco TelePresence System 3200
OL-14521-01
Chapter 5 Building the Lighting Assembly
Parts List
Step 20 Join the left, center, and right Reflector tops with the left and right Reflector Transition pieces.
Figure 5-20 Left and Right Reflector Transition pieces
Note Do not tighten screws until completing Step 22.
201143
21
28
20
27
18
17
