5-23
Cisco TelePresence System 3200
OL-14521-01
Chapter 5 Building the Lighting Assembly
Parts List
Step 21 Attach the left and right (vertical) Reflector ends to the left and right (vertical) Reflector Bottom ends.
Figure 5-21 Left and Right (vertical) Reflector ends
Note Do not tighten screws until completing Step 22.
201144
15
27
19
33 27
19
