4-5
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Chapter 4 Configuring a Supervisor Engine 720
Configuring and Monitoring the Switch Fabric Functionality
These sections describe how to monitor the switch fabric functionality:
• Displaying the Switch Fabric Redundancy Status, page 4-5
• Displaying Fabric Channel Switching Modes, page 4-5
• Displaying the Fabric Status, page 4-6
• Displaying the Fabric Utilization, page 4-6
• Displaying Fabric Errors, page 4-7
Displaying the Switch Fabric Redundancy Status
To display the switch fabric redundancy status, perform this task:
Router# show fabric active
Active fabric card in slot 5
No backup fabric card in the system
Router#
Displaying Fabric Channel Switching Modes
To display the fabric channel switching mode of one or all modules, perform this task:
This example shows how to display the fabric channel switching mode of module 2:
Router# show fabric switching-mode module 2
Module Slot Switching Mode
2 dCEF
Router#
This example shows how to display the fabric channel switching mode of all modules:
Router# show fabric switching-mode
Global switching mode is Compact
dCEF mode is not enforced for system to operate
Fabric module is not required for system to operate
Modules are allowed to operate in bus mode
Truncated mode is allowed
Module Slot Switching Mode
1 Crossbar
2 dCEF
3 dCEF
4 dCEF
5 Crossbar
6 dCEF
Command Purpose
Router# show fabric active
Displays switch fabric redundancy status.
Command Purpose
Router# show fabric switching-mode [module
{
slot_number | all]
Displays fabric channel switching mode of one or all
modules.
