Page #80 background image
4-6
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Chapter 4 Configuring a Supervisor Engine 720
Configuring and Monitoring the Switch Fabric Functionality
Router#
Displaying the Fabric Status
To display the fabric status of one or all switching modules, perform this task:
This example shows how to display the fabric status of all modules:
Router# show fabric status
slot channel speed module fabric
status status
1 0 8G OK OK
5 0 8G OK Up- Timeout
6 0 20G OK Up- BufError
8 0 8G OK OK
8 1 8G OK OK
9 0 8G Down- DDRsync OK
Router#
Displaying the Fabric Utilization
To display the fabric utilization of one or all modules, perform this task:
This example shows how to display the fabric utilization of all modules:
Router# show fabric utilization all
Lo% Percentage of Low-priority traffic.
Hi% Percentage of High-priority traffic.
slot channel speed Ingress Lo% Egress Lo% Ingress Hi% Egress Hi%
5 0 20G 0 0 0 0
9 0 8G 0 0 0 0
Router#
Command Purpose
Router# show fabric status [
slot_number
| all]
Displays fabric status.
Command Purpose
Router# show fabric utilization [
slot_number
| all]
Displays fabric utilization.
