Cisco 7940G Administration Guide

10
Cisco Unified IP Phone 7960G/7940G Administration Guide for Cisco Unified Communications Manager 7.0 (SIP)
OL-15499-01
Preface
Related Documentation
For more information about Cisco Unified IP Phones or Cisco Unified Communications Manager, refer
to the following publications:
Cisco Unified IP Phone 7960G/7940G Series
These publications are available at the following URL:
http://www.cisco.com/en/US/products/hw/phones/ps379/tsd_products_support_series_home.html
• Cisco Unified IP Phone 7960G/7940G Series Phone Guide
• Cisco Unified IP Phone Features A–Z
• Installing the Wall Mount Kit for the Cisco Unified IP Phone
• Regulatory Compliance and Safety Information for Cisco Unified IP Phones
• Open Source License Notices for the Cisco Unified IP Phones 7900 Series
Cisco Unified Communications Manager Administration
These publications are available at the following URL:
http://www.cisco.com/en/US/products/sw/voicesw/ps556/tsd_products_support_series_home.html
Cisco Unified Communications Manager Business Edition
These publications are available at the following URL:
http://www.cisco.com/en/US/products/ps7273/tsd_products_support_series_home.html
Chapter 5, “Configuring Features, Templates,
Services, and Users”
Provides an overview of procedures for configuring telephony features,
configuring directories, configuring phone button templates, setting up
services, and adding users to Cisco
Unified Communications Manager
Chapter 6, “Viewing Status, Statistics, and
Firmware Information on the Cisco
Unified IP Phone”
Explains how to view model information, status messages, network
statistics, and firmware information from the
Cisco Unified IP Phone
Chapter 7, “Troubleshooting and Maintenance” Provides tips for troubleshooting the Cisco Unified IP Phone
Appendix A, “Providing Information to Users Via
a Website”
Provides suggestions for setting up a website for providing users with
important information about their Cisco
Unified IP Phones
Appendix B, “Feature Support by Protocol for
Cisco Unified IP Phone”
Provides information about feature support for the Cisco Unified
IP
Phone 7960G and 7940G using the SCCP or SIP protocol with Cisco
Unified Communications Manager Release 7.0.
Appendix C, “Supporting International Users” Provides information about setting up phones in non-English
environments
Appendix D, “Technical Specifications” Provides technical specifications of the Cisco Unified IP Phone.
Appendix E, “Basic Phone Administration Steps” Provides procedures for basic administration tasks such as adding a user
and phone to Cisco Unified Communications Manager and then
associating the user to the phone.
Chapter Description

Cisco 7940G Specifications

General

Keypad number of keys	12
Touchscreen	-
Speakerphone	Yes
Voice codecs	G.711, G.729a
Bluetooth	No
Supported network protocols	DHCP, SCCP, SIP, MGCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3 FCC 68 (CFR47) HAC IC CS-03
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
