Cisco 7940G Administration Guide

1-9
Cisco Unified IP Phone 7960G/7940G Administration Guide for Cisco Unified Communications Manager 7.0 (SIP)
OL-15499-01
Chapter 1 An Overview of the Cisco Unified IP Phone
Overview of Configuring and Installing Cisco Unified IP Phones
Overview of Configuring and Installing Cisco Unified IP Phones
When deploying a new IP telephony system, system administrators and network administrators must
complete several initial configuration tasks to prepare the network for IP
telephony service. For
information and a checklist for setting up and configuring a complete Cisco
Unified IP telephony
network, refer to the “System Configuration Overview” chapter in Cisco Unified Communications
Manager System Guide.
After you have set up the IP telephony system and configured system-wide features in Cisco Unified
Communications Manager, you can add IP phones to the system.
The following topics provide an overview of procedures for adding Cisco Unified IP Phones to your
network:
• Configuring Cisco Unified IP Phones in Cisco Unified Communications Manager, page 1-9
• Installing Cisco Unified IP Phones, page 1-12
Configuring Cisco Unified IP Phones in Cisco Unified Communications
Manager
To add phones to the Cisco Unified Communications Manager database, you can use:
• Auto-registration
• Cisco Unified Communications Manager Administration
• Bulk Administration Tool (BAT)
For more information about these choices, see the “Adding Phones to the Cisco Unified Communications
Manager Database” section on page 2-7.
Ta b l e 1-3 Overview of Security Features
Feature Description
Image authentication Signed binary files (with the extension .sbn) prevent tampering with the firmware image
before it is loaded on a phone. Tampering with the image causes a phone to fail the
authentication process and reject the new image.
Encrypted configuration files Lets you ensure the privacy of phone configuration files.
Phone hardening Additional security options, which you control from Cisco Unified Communications
Manager Administration:
• Disabling PC port
• Disabling Gratuitous ARP
• Disabling PC Voice VLAN access
• Disabling access to the Setting menus, or providing restricted access that allows
access to the User Preferences menu and saving volume changes only
Note You can view current settings for the PC Port Disabled, GARP Enabled, and Voice
VLAN enabled options by looking at the phone’s Network Configuration menu.
For more information, see the
“Displaying a Configuration Menu” section on
page 4-2.

Cisco 7940G Specifications

General

Keypad number of keys	12
Touchscreen	-
Speakerphone	Yes
Voice codecs	G.711, G.729a
Bluetooth	No
Supported network protocols	DHCP, SCCP, SIP, MGCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3 FCC 68 (CFR47) HAC IC CS-03
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
