1-3
Cisco Unified IP Phone 7975G Administration Guide for Cisco Unified Communications Manager 6.0
OL-12642-01
Chapter 1 An Overview of the Cisco Unified IP Phone
Understanding the Cisco Unified IP Phone 7975G
4 Messages button Auto-dials your voice message service (varies by service).
5 Directories button Opens/closes the Directories menu. Use it to access call logs and directories.
6 Help button Activates the Help menu.
7 Settings button Opens/closes the Settings menu. Use it to change touchscreen and ring
settings.
8 Services button Opens/closes the Services menu.
9 Volume button Controls the handset, headset, and speakerphone volume (off-hook) and the
ringer volume (on-hook).
10 Speaker button Toggles the speakerphone on or off.
11 Mute button Toggles the Mute feature on or off.
12 Headset button Toggles the headset on or off.
13 4-way navigation
pad and Select
button (center)
Allows you to scroll through menus and highlight items. Use the Select button
to select an item that is highlighted on the screen.
Navigation button
• Scroll up and down to see menus and highlight items.
• Scroll right and left to scroll horizontally in multi-column displays.
Select button—scroll to highlight a line using the Navigation button, and
then:
• Press to open a menu.
• Press to play a ringer item.
• Press to access other features as described on the screen.
Note The Select button does not take action on all menu items.
14 Keypad Allows you to dial phone numbers, enter letters, and choose menu items.
15 Softkey buttons Each activates a softkey option (displayed on your touchscreen).
16 Handset light strip Indicates an incoming call or new voice message.
17 Touchscreen Shows phone features.
