4-26
Cisco Unified IP Phone 7975G Administration Guide for Cisco Unified Communications Manager 6.0
OL-12642-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Device Configuration Menu
Ethernet Configuration Menu
The Ethernet Configuration menu includes the options that are described in Table 4-14.
Table 4-14 Ethernet Configuration Menu Option
Option Description To Change
Span to PC Port Indicates whether the phone will
forward packets transmitted and
received on the network port to the
access port.
Enable this option if an application that
requires monitoring of the phone’s
traffic is being run on the access port.
These applications include monitoring
and recording applications (common in
call center environments) and network
packet capture tools that are used for
diagnostic purposes.
From Cisco Unified Communications
Manager Administration, choose Device
> Phone > Phone Configuration.
Forwarding
Delay
Indicates whether the internal switch
begins forwarding packets between the
PC port and switched port on the phone
when the phone becomes active.
• When forwarding delay is set to
disabled, the internal switch begins
forwarding packets immediately.
• When forwarding delay is set to
enabled, the internal switch waits
eight seconds before forwarding
packets between the PC port and
the switch port.
Default is disabled.
From Cisco Unified Communications
Manager Administration, choose Device
> Phone > Phone Configuration.
