Cisco 860 Series User Manual

3-38
Cisco Integrated Services Router Hardware Installation Guide
Chapter 3 Connecting the Router
Cisco 860, 880, 890 Series
Step 2 To secure the power cord to the router, attach the power lock clip to the power cord, slide the clip to the
end of the DC plug, and secure the retaining clip into the router chassis. See Figure 3-34.
Figure 3-34 Securing the Power Cord
1 Power lock clip 3 DC plug
2 Power cord 4 Lock holes on either side of the power
connector
270659
4
2
1
3

Cisco 860 Series Specifications

General

VPN Support	Yes
Firewall	Yes
QoS	Yes
Data Link Protocol	Ethernet, Fast Ethernet
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS
Operating System	Cisco IOS
Device Type	Router
WAN Interfaces	1 x 10/100Base-TX - RJ-45
LAN Interfaces	4 x 10/100Base-TX - RJ-45
Connectivity Technology	Wired
Network / Transport Protocol	IPSec, TCP/IP
Features	DHCP support, NAT support, VLAN support, IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u
