Navigation
Use the outer ring of the Navigation cluster to scroll through menus. Use the inner Select button of the
Navigation cluster to select menu items.
If a menu item has an index number, you can enter the index number with the keypad to select the item.
Phone Screen Features
The phone screen shows information about your phone such as directory number, active call and line status,
softkeys, speed dials, and placed calls. The screen is made up of these sections:
Header sectiondisplays the phone number, Wi-Fi strength, battery charge, and a number of feature
icons. The feature icons display when features are active.
Middle sectiondisplays the home screen with its application (app) icons.
Footer sectiondisplays the current date and time or softkey labels. Each softkey label indicates the
action for the softkey button below the screen.
Differences Between Phone Calls and Lines
We use the terms lines and calls in very specific ways to explain how to use your phone. Here is an explanation
of the differences.
Lines
Each line corresponds to a directory number or intercom number that others can use to call you. Your
phone supports up to six lines. To see your phone lines, press Phone to open the line view. You
have as many lines as you have directory numbers with phone line icons in the line view list.
Calls
Each line can support multiple calls, typically up to four calls. Your phone can support up to 24 connected
calls, but your system administrator can adjust this number according to your needs. Only one call can
be active at any time; other calls are automatically placed on hold.
Here is an example: If you have two lines and each line supports four calls, then you could have up to eight
connected calls at one time. Only one of those calls is active and the other seven are held calls.
Cisco Wireless IP Phone 8821 and 8821-EX User Guide
12
Your Phone
Navigation

Table of Contents

Other manuals for Cisco 8821

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco 8821 and is the answer not in the manual?

Cisco 8821 Specifications

General IconGeneral
Wi-FiYes
Ethernet LANNo
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version3.0+HS
Security algorithmsEAP-FAST, EAP-TLS, PEAP, WPA
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.11r
USB 2.0 ports quantity1
Voice codecsG.711, G.711a, G.722, G.729, G.729ab, iLBC
Volume controlDigital
Product typeIP mobile phone
Product colorBlack
Input frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output current0.2 A
Display diagonal2.4 \
Display resolution240 x 320 pixels
Frequency band2.412, 2.472, 5.180, 5.240, 5.260, 5.320, 5.500, 5.700, 5.745, 5.825 GHz
Lines quantity- lines
Phonebook capacity- entries
Storage temperature (T-T)-30 - 60 °C
Operating temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)10 - 95 %
SafetyUL 60950-1, CAN/CSA 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950.1, IEC 60529 (IP 67)
Certification● 47 CFR 15 B ● ICES-003 B ● EN 55022 B ● AS/NZS CISPR 22 B ● CISPR 22 B ● VCCI B ● EN 61000-3-2 ● EN 61000-3-3 ● KN 22 B ● EN 55024 ● EN 50082-1 ● EN 61000-6-1 ● EN61000-6-3 ● EN 300386 ● EN 60601-1-2 ● KN
Number of handles included1 pc(s)
Harmonized System (HS) code85171800
Weight and Dimensions IconWeight and Dimensions
Depth17 mm
Width56 mm
Height132 mm
Weight126 g
