Cisco ASR 907 User Manual

SignalPinSignal NamePin Number
Open58Open26
Open59Open27
Open60Open28
Open61Open29
Open62Open30
Open63Open31
Open64Open32
Table 24: Port 24-47 RX
SignalPinSignal NamePin Number
RX Tip Port 2433RX Ring Port 241
RX Tip Port 2534RX Ring Port 252
RX Tip Port 2635RX Ring Port 263
RX Tip Port 2736RX Ring Port 274
RX Tip Port 2837RX Ring Port 285
RX Tip Port 2938RX Ring Port 296
RX Tip Port 3039RX Ring Port 307
RX Tip Port 3140RX Ring Port 318
RX Tip Port 3241RX Ring Port 329
RX Tip Port 3342RX Ring Port 3310
RX Tip Port 3443RX Ring Port 3411
RX Tip Port 3544RX Ring Port 3512
RX Tip Port 3645RX Ring Port 3613
RX Tip Port 3746RX Ring Port 3714
RX Tip Port 3847RX Ring Port 3815
RX Tip Port 3948RX Ring Port 3916
RX Tip Port 4049RX Ring Port 4017
RX Tip Port 4150RX Ring Port 4118
Cisco ASR 907 Router Hardware Installation Guide
167
Troubleshooting
AMP64 Pinouts

Cisco ASR 907 Specifications
