Table 35: Interface Module LEDs
DescriptionColor/StateLED
Disabled/no power to IMOffPower (PWR)
Enabled and power rails on IM in rangeGreen
Disabled/power-down
OffStatus (STAT)
Failure (on at reset)Red
Booting (if local CPU)Flashing Red
OperationalGreen
Inactive or no connection
OffLink status (L)
Fault/loop conditionAmber
Ok with activity or no activityGreen
Inactive port status
OffSpeed (S)
Activity or no activityGreen
1-Port OC-192 or 8-Port Low Rate CEM Interface Module LEDs
The table summarizes the LEDs for the 1-Port OC-192 or 8-Port Low Rate CEM Interface Module.
Meaning (Default=Off)Color/StateLED
All power rails are within specGreenPower (PWR)
DisabledRed
No power to IMOff
Operational
GreenOperating Status (STAT)
FailureRed
Disabled or power-downOff
Link Up
Solid GreenSFP Link (Left LED)
Link ActivityFLASH Green
Fault or Error or AlarmSolid Yellow
RFUFLASH Yellow
Disabled or No LinkOff
Cisco ASR 907 Router Hardware Installation Guide
184
Troubleshooting
1-Port OC-192 or 8-Port Low Rate CEM Interface Module LEDs
